Stainless International supply a range of Stainless Steel Rectangular Section in standard sizes and dull polished 220/240 grit finish.
Rectangular box sections offer excellent load-bearing properties and are widely used in frameworks, support structures, and industrial applications. The elongated shape provides added strength in one direction, making them suitable for specific design needs.
| Dimensions (mm) | Wall (mm) | Dimensions (mm) | Wall (mm) |
|---|---|---|---|
| 20×10 | 1.50 | 60×40 | 1.50 |
| 30×10 | 1.20 | 60×40 | 2.00 |
| 30×10 | 1.50 | 60×40 | 3.00 |
| 30×15 | 1.20 | 80×40 | 1.50 |
| 30×15 | 1.50 | 80×40 | 2.00 |
| 30×20 | 1.20 | 80×40 | 3.00 |
| 30×20 | 1.50 | 80X40 | 4.00 |
| 40X15 | 1.50 | 80×40 | 5.00 |
| 40.20 | 1.20 | 80×60 | 3.00 |
| 40×20 | 1.50 | 100X40 | 1.50 |
| 40×20 | 2.00 | 100X40 | 3.00 |
| 50×25 | 1.20 | 100X50 | 2.00 |
| 50X25 | 1.50 | 100X50 | 3.00 |
| 50X25 | 2.00 | 100X50 | 4.00 |
| 50X25 | 3.00 | 100×50 | 5.00 |
| 50×30 | 1.50 | 100×60 | 3.00 |
| 50×30 | 3.00 | 120X60 | 3.00 |
| 60X20 | 1.50 | 120×80 | 3.00 |
| 60X20 | 2.00 | 150X100 | 3.00 |
| 60X30 | 1.20 | 150×100 | 5.00 |
| 60×30 | 2.00 |
